Dawei ECG Machine 3 Channel

Name: Dawei ECG Machine 3 Channel
Brand: Regal Medical
SKU: ECG01
Price: 2150.00 AED
Availability: InStock

2,150.00 .د. إ

Sale Sold out

DE-03

The touch operation leads you through acquisition, analysis, storage, printing, and accessing previous ECGs with ease. Further enhancing efficiency, worklists and patient demographics can be downloaded

Description

Streamlined Workflow

12-lead automatic ECG analysis system: ECG

automatic diagnosis function, automatic ECG

measurement and analysis for doctors' reference;

User-friendly Design

7-inch high-definition and wide-angle color LCD

screen, capacitive touch control, 12-lead display;

Built-in large capacity any ion recharge able

battery, and a special charging circuit and perfect

battery management and protection system;

Language: CHN ENG RUS FREN GER PORTU SPAN

Accurate clinnical performances

Seven ECG record combination modes;

Single line /3 channel/(3+R) channel/(+l+V5)

channel/double line 6 channel/single line 6 channel/sin

gle/double line 12 channels eight ECG display combina

tion mode;

ECG suction ball

Limb clip

Cable plug

Data Management

Can be connected to the ECG workstation, with a strong

patient file management function, can store up to

hundreds of thousands of ECG reports;

500 case of memory，can be expanded memory capacity

by Udisk;

ECG reports

100,000

Memory

500

Weight

● 12-lead synchronous ECG acquisition
● Equipped with high speed and high sensitivity hot spot recording system, with print trace depth adjustment function
● Six ECG record combination modes
● 3 channels/ (3+R) channels/dual-row 6-channels/single-row 6-channels/single/dual-row 12-channels six ECG display combination modes;
● Accurate ECG automatic diagnosis function, with heart rate exceeding alarm function, and freely set whether to print the measurement and analysis report;
● Full keyboard touch input to enter hospital and patient information;
● With real-time ECG waveform freezing function, it is easy to grasp the patient's important ECG waveform;
● Manual, automatic, rhythm, physical examination and other operating modes;
● With RS232 communication interface, USB interface and LAN network interface;
● With lead off detection function, with paper shortage detection function;
● Wide power supply design, suitable for 110-230, 50/60hz ac power supply.
